Liquid Temperature Sensor

Login to view prices

NTC sensor for liquid temperature measurement

Description

NTC sensor for liquid temperature measurement , hi accurance in wide range

Very compact size with M6 connection. Reference characteristic 3 Kohm at 20 Celsius .

  • NTC Sensor
  • -50 to +150°C Temperature Range
  • Accuracy 2% FS
  • Reference Thermistor 3Kohm@25°C
  • Respose time (0-90%)  1000mS
  • Stainless Steel
  • Thread M6
  • Wheight 5gr ( no cable )

Additional information

Weight 0,12 kg

DATASHEET

Here the datasheet :

SEN_TSN_M6_DATASHEET_v2.0
